| Prime Power | kVA | 365,0 |
| Prime Power | kW | 292,0 |
| Standby | kVA | 400,0 |
| Standby Power | kW | 320,0 |
| Standart Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Rated At Power Factor | Cos Phi | 0,8 |
| Brand | BAUDOUIN | |
| Model | 6M21G400-5 | |
| Cylinder Configuration | In-Line | |
| Number of cylinders | 6 | |
| Cylinder Volume | 12,54 | |
| Cylinder Diameter | 127 | |
| Cylinder Length | 165 | |
| Compression Ratio | 16:01 | |
| Ventilation Type | Turbo-charged – Aftercooler | |
| Governor Type | Electronic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 47 |
| Total Oil capacity | lt | 30 |
| Electrical System (DC) | 24 | |
| Speed/Frequency | rpm | 1500/50 |
| Engine Power | kW | 385 |
| 110% Fuel Consumption at Load | lt | 91,3 |
| Fuel Consumption at 100% Load | lt | 82,1 |
| 75% ESP Fuel Consumption at Load | lt | 60,7 |
| 50% ESP Fuel Consumption at Load | lt | 41 |
| Exhaust Exhaust Temperature | °C | 580 |
| Exhaust Gas Flow | m3/min | 65 |
| Combustion Air Flow | m3/min | 24 |
| Cooling Fan Flow | m3/min | 398 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Single | |
| Number of Poles | (V) | 4 |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | % | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1400X3050X1723 |
| Weight | kg | 2696 |
| Fuel Tank Capacity | lt | 600 |
Dimensions With Canopy and Weight |
||
| Width x Length x Height | mm | 1400X4800X2030 |
| Weight | kg | 3296 |
| Fuel Tank Capacity | lt | 600 |
