| Prime Power | kVA | 320,0 |
| Prime Power | kW | 256,0 |
| Standby | kVA | 355,0 |
| Standby Power | kW | 284,0 |
| Standart Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Rated At Power Factor | Cos Phi | 0,8 |
| Brand | BAUDOUIN | |
| Model | 6M16G350-5 | |
| Cylinder Configuration | In-Line | |
| Number of cylinders | 6 | |
| Cylinder Volume | 9,726 | |
| Cylinder Diameter | 126 | |
| Cylinder Length | 130 | |
| Compression Ratio | 17:01 | |
| Ventilation Type | Turbo-charged – Aftercooler | |
| Governor Type | Electronic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 50 lt |
| Total Oil capacity | lt | 26 |
| Electrical System (DC) | 24 | |
| Speed/Frequency | rpm | 1500/50 |
| Engine Power | kW | 320 |
| 110% Fuel Consumption at Load | lt | 78,4 |
| Fuel Consumption at 100% Load | lt | 70,5 |
| 75% ESP Fuel Consumption at Load | lt | 52,3 |
| 50% ESP Fuel Consumption at Load | lt | 35,4 |
| Exhaust Exhaust Temperature | °C | 550 |
| Exhaust Gas Flow | m3/min | 58,2 |
| Combustion Air Flow | m3/min | 20,8 |
| Cooling Fan Flow | m3/min | 450 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Single | |
| Number of Poles | (V) | 4 |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | % | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1200X3020X1670 |
| Weight | kg | 2453 |
| Fuel Tank Capacity | lt | 450 |
Dimensions With Canopy and
Weight |
||
| Width x Length x Height | mm | 1200X4100X1930 |
| Weight | kg | 2998 |
| Fuel Tank Capacity | lt | 450 |
