| Prime Power | kVA | 300 |
| Prime Power | kW | 240 |
| Standby Power | kVA | 350 |
| Standby Power | kW | 280 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Brand | PERKINS | |
| Model | 1706A-E93TAG1 | |
| Cylinder Configuration | Inline | |
| Number of cylinders | 6 | |
| Cylinder Volume | 9,29 | |
| Cylinder Diameter | 115 | |
| Cylinder Length | 149 | |
| Compression Ratio | 16,5:1 | |
| Ventilation Type | Turbo-charged | |
| Governor Type | Electronic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 35,8 |
| Total Oil capacity | lt | 30 |
| Electrical System (DC) | 24 | |
| Speed/Frequency | rpmz | 1500/50 |
| Engine Power | kW | 303,9 |
| 110% Fuel Consumption at Load | lt | 69,2 |
| Fuel Consumption at 100% Load | lt | 63,3 |
| 75% ESP Fuel Consumption at Load | lt | 48,5 |
| 50% ESP Fuel Consumption at Load | lt | 34,1 |
| Exhaust Exhaust Temperature | °C | 549 |
| Exhaust Gas Flow | m3/min | 44,5 |
| Combustion Air Flow | m3/min | 16,5 |
| Cooling Air Flow | m3/min | TBA |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Tek | |
| Number of Poles | 4 | |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1200X3000X1671 |
| Fuel Tank Capacity | mm | 450 |
| Weight | kg | 2350 |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1200X4100X1930 |
| Fuel Tank Capacity | mm | 450 |
| Weight | mm | 2895 |
