| Prime Power | kVA | 135 |
| Prime Power | kW | 108 |
| Standby Power | kVA | 150 |
| Standby Power | kW | 120 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Brand | PERKINS | |
| Model | 1106A-70TG1 | |
| Cylinder Configuration | Inline | |
| Number of cylinders | 6 | |
| Cylinder Volume | 7,01 | |
| Cylinder Diameter | 105 | |
| Cylinder Length | 135 | |
| Compression Ratio | 18,2:1 | |
| Ventilation Type | Turbo-charged – Intercooler | |
| Governor Type | Mechanic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 21 |
| Total Oil capacity | lt | 16,5 |
| Electrical System (DC) | 12 | |
| Speed/Frequency | rpmz | 1500/50 |
| Engine Power | kW | 137 |
| 110% Fuel Consumption at Load | lt | 33,8 |
| Fuel Consumption at 100% Load | lt | 30,28 |
| 75% ESP Fuel Consumption at Load | lt | 22,7 |
| 50% ESP Fuel Consumption at Load | lt | 15,9 |
| Exhaust Exhaust Temperature | °C | 576 |
| Exhaust Gas Flow | m3/min | 22,66 |
| Combustion Air Flow | m3/min | 8,09 |
| Cooling Air Flow | m3/min | 182 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Tek | |
| Number of Poles | 4 | |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1100X2500X1402 |
| Fuel Tank Capacity | mm | 300 |
| Weight | kg | 1471 |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1100X3700X1680 |
| Fuel Tank Capacity | mm | 300 |
| Weight | mm | 1876 |
