| Prime Power | kVA | 10 |
| Prime Power | kW | 8 |
| Standby Power | kVA | 11 |
| Standby Power | kW | 8,8 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Brand | YANGDONG | |
| Model | YDD380D | |
| Cylinder Configuration | In Line | |
| Number of cylinders | 3 | |
| Cylinder Volume | 1,35 | |
| Cylinder Diameter | 80 mm | |
| Cylinder Length | 90 mm | |
| Compression Ratio | 18 | |
| Ventilation Type | Natural Aspirasyon | |
| Governor Type | Mechanic | |
| Cooling Type | Water | |
| Toğlam Cooling Capacity | lt | 3,4 |
| Total Oil capacity | lt | 4,5 |
| Electrical System (DC) | 12 | |
| Speed/Frequency | rpmz | 1500/50 |
| Engine Power | kW | 11 KW |
| 110% Fuel Consumption at Load | lt | – |
| Fuel Consumption at 100% Load | lt | 3,1 |
| 75% ESP Fuel Consumption at Load | lt | 2,86 |
| 50% ESP Fuel Consumption at Load | lt | 2,23 |
| Exhaust Exhaust Temperature | °C | 500 |
| Exhaust Gas Flow | m3/min | 1,96 |
| Combustion Air Flow | m3/min | TBA |
| Cooling Fan Flow | m3/min | TBA |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Single | |
| Number of Poles | (V) | 4 |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | % | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 730X1300X930 |
| Fuel Tank Capacity | lt | 100 |
| Weight | kg | 385 |
Dimensions With Canopy and Weight |
||
| Width x Length x Height | mm | 730X2100X1200 |
| Fuel Tank Capacity | lt | 100 |
| Weight | kg | 541 |
