| Prime Power | kVA | 105 |
| Prime Power | kW | 84 |
| Standby Power | kVA | 112 |
| Standby Power | kW | 90 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Engine Model | SC4H115D2 | |
| Standby Power | kWm | 86 |
| Prime Power | kWm | 82 |
| Number of Transfers | (r.p.m) | 1500 |
| Cylinder Volume | (L) | 4,3 |
| Number of Cylinders | 4 Sıralı | |
| Broke x Stroke | (mm x mm) | 105 x 124 |
| Compression Ratio | 17,3 : 1 | |
| Governor Type | Electronic | |
| Ventilation System | TURBOCHARGED | |
| Injection System | Direct | |
| Cooling System | Water | |
| 100% Fuel Consumption at Load | (L/h) | 20 |
| 75% Fuel Consumption at Load | (L/h) | 15 |
| Fuel Consumption at 50% Load | (L/h) | 10 |
| Total Oil Capacity | lt. | 13 |
| Total Cooling Capacity | lt. | 6,8 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Single | |
| Number of Poles | (V) | 4 |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | % | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1000X2000X1382 |
| Fuel Tank Capacity | lt. | 215 |
| Weight | kg | 1096 |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1000X3100X1600 |
| Fuel Tank Capacity | lt. | 215 |
| Weight | kg | 1416 |
